High Safety
- Good Safety System
- Emergency Opening
Aesthetics
- Transparent and elegant design
- High-quality assembly and surface treatment process
Connectivity
- Multi-function connection with the third part equipment
High Quality
- KeeDas Classics
- High-quality Stainless Steel
- Famous motor system
High Throughput
- Rapid open and close
- Beautiful indicator
- Fast reaction for ID recognition system
| Specifications | |
| Power | 220VAC 50/60Hz, ≤300W |
| Motor | Brushless DC motor |
| Passage width | Indoor :550 – 900mm, outdoor: 550-1100mm |
| Dimension | 1560mm x 220mm x 1000mm |
| Housing material | 304 brushed stainless steel， 2mm |
| Mobile leaf | 8mm tempered glass/10mm acrylic |
| Safety beam | 24 infra red beam |
| Operating time | ≤0.6s |
| Throughput | 30-60 person/m |
| Operating
temperature |
-20 ~ 60 ℃ |
| MCBF | ≥500,0000 |
| Humidity | 5%~80% |
| Sound level | ＜ 60dB |
| Interface | CAN bus, RS232，RS485，I/O
(TCP/IP Optional) |
| Protection | IP40 |
